Katana-Mini
Katana-Mini
Serious Rock DNA Forged Into a Compact, Battery-Powered Amp
BOSS Katana amps have received accolades from guitarists everywhere for their fantastic sound and feel, onboard effects, and great value. Now, the Katana-Mini makes serious Katana tone accessible in a small, go-anywhere amp that runs on batteries. Offering sound quality that far exceeds other amps in its class, this miniature powerhouse features an authentic multi-stage analog gain circuit for big, expressive sound, plus a traditional analog EQ and an onboard tape-style delay. Ultra-compact and travel-ready, the Katana-Mini delivers inspiring Katana tone anywhere you want to play.
FEATURES
- Great Katana tone in a highly portable amp
- Rich, full sound that far exceeds other amps in its class
- Authentic multi-stage analog gain circuit and three-band analog tone stack
- Three versatile amp types: Brown, Crunch, and Clean
- Built-in tape-style delay for warm ambience
- Aux input for jamming with music from a smartphone
- Phones/recording output with cabinet voicing
- Runs on six AA-size batteries or optional AC adapter
SPECIFICATIONS
Rated Power Output
7 W
Nominal Input Level
INPUT: -10 dBu (1 M ohm)
AUX IN: -10 dBu (20 k ohm)
Speaker
10 cm (4 inches)
Connectors
INPUT jack: 1/4-inch phone type
AUX IN jack: Stereo miniature phone type
PHONES/REC OUT jack: Stereo miniature phone type
DC IN jack
Power Supply
Alkaline battery (AA, LR6) x 6
Rechargeable Ni-MH battery (AA, HR6) x 6
or
AC adaptor (sold separately)
Width
230 mm | 9-1/16 inches
Depth
116 mm | 4-5/8 inches
Height
181 mm | 7-1/8 inches
Weight (including battery)
1.2 kg | 2 lbs 11 oz
