Samson Audio
Graphite 49 MIDI Controller
Graphite 49 MIDI Controller
The Samson Graphite 49 USB MIDI Controller gives you all the performance and production control you need to get the most out of your music software. Combining an intuitive 49-key semi-weighted keyboard with a feature set that is both useful and accessible, the Graphite 49 is a sleek, powerful tool that allows you to express your most dynamic musical ideas.
FEATURES
- 49-key semi-weighted keyboard with aftertouch
- 9 programmable faders, 8 encoders, and 16 buttons for hands-on control over your DAW and virtual instruments
- 4 velocity-sensitive trigger pads with aftertouch (two banks) for drum sounds and samples
- Large LCD display provides real-time feedback
- Includes MIDI Out, USB, and sustain pedal connections
- Compact design, perfect for live performance and studio applications
- Dedicated Transpose and Octave buttons, Pitch Bend and Modulation wheels
- 4 zones for creating splits and layering sounds
- Adjustable velocity curve for both keys and pads
- iPad and USB bus powered
SPECIFICATIONS
Keyboard
49-note, semi-weighted, velocity sensitive, with aftertouch
Display
Large backlit LCD
Sliders
9
Encoders
8
Function Buttons
16
Trigger Pads
4
Transport Controls
5 (Rewind, Fast Forward, Stop, Play, Record)
Wheels
Pitch Bend, Modulation
Key Range
Octave +/–, Transpose +/–
Operation Controls
MAIN, SETUP, PRESET, ZONE, MUTE, BANK A/B, BANK ◀ / ▶, CHANNEL ◀ / ▶, PAGE◀ / ▶, DATA +/–, ENTER
Presets
30 (1 Graphite, 2-10 Remote Control, 11-30 User)
Functions Keys
0-9, Enter, Aftertouch, KB Vel, Pad Vel, Drawbar, Local, Preset
Pedal Input
1/4" TS
MIDI
MIDI over USB, 5-Pin MIDI OUT
Power
USB Bus Power, 9V 300mA (not included)
Accessories
USB Cable
Dimensions
31.4" x 9.75" x 3.3" / 797mm x 247mm x 84mm
Weight
10.2lb / 4.6kg
