The PLX-1000 is precision engineered for the booth, drawing on 50 years’ experience of making high-end turntables. The result is a familiar layout with some next generation improvements, including a high-torque direct drive system, multi-pitch control, club-grade build and sound quality, and detachable power and audio cables.
FEATURES
Accessories
Power cord
Audio cable
Ground wire
Adapter for EP record
Turntable sheet
Slip mat and sheet
Dust cover
Head shell
Balance, sub and shell weights
Operating instructions
Specifications
Width: 17.83 in
Depth: 13.9 in
Height: 6.26 in
Weight: 32.19 lb
Turntables
Drive Method: Quartz lock, servo-type, direct drive
Platter: Aluminium, die-casting diameter: 332 mm
Motor: 3-phase, brushless DC motor
Braking System: Electronic brake
Rotation Speed: 33⅓ rpm, 45 rpm
Rotation Adjustment Range: ±8, ±16, ±50 %
Wow and Flutter: 0.1 % or less WRMS (JIS WTD)
Signal-to-Noise Ratio: 70 dB
Starting Torque: > 4.5 kgf・cm
Start Time: 0.3 sec (at 33⅓ rpm)
Tone Arm
Arm Type: Universal type S-shape tone arm
Overhang: 0.59 in
Effective Length: 9.06 in
Tracking Error: Within 3°
Height Adjustment Range: 0.24 in
Stylus Pressure Variable Range: 0-4 g (1 scale 0.1 g)
Cartridge Weight Single: 2.5-12 g (includes mounting materials)
